31
APX
Holder (Screw-in type)
APX3000R254M12A35 SC25M12S125SW
Insert (Grade)
AOMT123620PEER-M (MP9120)
Work Material
Ti-6Al-4V
Cutting Speed
vc40 m/min (n510 min
-1
)
Feed
fz0.08 mm/tooth (vf160 mm/min)
Depth of Cut
ap6 mm, ae25 mm
Coolant
Emulsion
Screw-in head
Carbide shank
Edge condition (85 min.)
Rough Pocket Milling
Depth 80 mm
Double-phased
helical rake
angles
Tough cutting edge
(Convex curve)
LANDING GEAR
Work Material [Titanium Alloy]
Key Point on Machining
Abnormal damage of the cutting edge such as chipping and vibration
can occur easily when rough machining titanium alloy. APX series
enables stable machining due to the employment of a low cutting
resistance insert with a unique convex curve cutting edge and a high
rigidity cutter body with internal coolant holes.
Application Example
Long tool life is achieved even on long reach applications by combining a screw-in head with a
carbide shank.
High rigidity cutter body
Low cutting resistance insert
