24
SMART
MIRACLE
0.5
0
1
End mill
(ø 6/R3) 4 flute Smart Miracle taper ball nose end mill
Work Material
Inconel® 718
Cutting Speed
vc113 m/min (n6000 min-1)
Feed
fz0.06 mm/tooth (vf1440 mm-min)
Depth of Cut
ap0.4 mm, ae 0.5 mm
Coolant
Emulsion
Finish Profile
Milling
ENGINE
Work Material [Ni-based Superalloy]
Application Example
Achieved 1.5 times longer tool life and stable machining without vibration.
Conventional
Tool life (Number of work pieces)
Wider chip
pocket
Variable
curve
Variable
pitch
Key Point on Machining
Ni-based alloys that have low thermal conductivity and are prone to work hardening require a
superior coated grade combined with an optimum cutting edge to be machined effectively.
The latest SMART MIRACLE vibration control ball nose end mills have variable pitch geometry
with newly designed cutting edges to reduce vibration.
Variable pitch
SMART MIRACLE Coating
Newly designed cutting edges
reduce vibration
SMART MIRACLE
Vibration Control ball nose end mill
