35
MNS
Drilling
LANDING GEAR
Work Material [Titanium Alloy]
Key Point on Machining
Adhesion and concentration of heat on the cutting edge occur easily during drilling
of titanium alloys because of the low thermal conductivity, thus it is important to
remove heat from the cutting edge efficiently and to evacuate chips smoothly. MNS
drills provide stable drilling with excellent cooling and chip discharge performance
due to the unique arrangement of coolant holes and the employment of optimum
flute shape respectively.
Application Example
Achieves stable machining due to excellent cooling and chip discharge.
Outstanding sharpness
and high edge strength
Excellent cooling
performance
Improved chip removal
Drill (Grade)
MNS0600X20DB (TF15)
Work Material
Ti-6Al-4V
Cutting Speed
vc30 m/min
Feed
f0.06 mm/rev
Hole Depth
120 mm
Coolant
Emulsion (3 MPa)
