32
VQ4SVB
30
0
60
90
VQ6SVB
End mill
VQ4SVBR0600
Work Material
Ti-10V-2Fe-3Al
Cutting Speed
vc200 m/min (n5300 min
-1
)
Feed
vf1590 mm/min
Depth of Cut
ap1.0 mm, ae0.5 mm
Coolant
Emulsion
Finish Profile Milling
Wider
chip
pocket
Variable
curve
Variable pitch
LANDING GEAR
Work Material [Titanium Alloy]
Key Point on Machining
When profile machining titanium alloy, vibrations, chipping and
abnormal damage of the cutting edge can occur. Use of a tool which is
designed for vibration control is effective. The latest SMART MIRACLE
vibration control ball nose end mills have variable pitch geometry
with a newly designed cutting edge geometry to reduce vibration.
Application Example
Stable machining is achieved without vibration. Tool life is approximately 3 times longer when
using the 6 flute type due to the increase in the number of flutes.
Tool life (min)
Variable pitch
SMART MIRACLE Coating
Newly designed cutting edge
reduces vibration
Smart Miracle
Vibration control ball nose end mill
