33
iMX
30
0
60
90
Head (Grade)
IMX16C10HV160R10016 (EP7020)
Holder
IMX16-U16N056L110C
Work Material
Ti-6Al-4V
Cutting Speed
vc150 m/min (n3000 min
-1
)
Feed
fz0.05 mm/tooth (vf1500 mm/min)
Depth of Cut
ap12 mm, ae0.5 mm
Coolant
Emulsion
No vibration
Chatter marks
Finish Pocket Milling
LANDING GEAR
Work Material [Titanium Alloy]
Key Point on Machining
When profile machining titanium alloy, vibrations, chipping and
abnormal damage of the cutting edge can occur. Use of a tool which is
designed for vibration control is effective. Exchangeable head end
mills with variable pitch geometry prevents vibration and improves
chip discharge performance.
Application Example
Up to 7 times tool life and stable machining are achieved without vibration.
Conventional
Tool life (min)
High Precision
High Rigidity
Low Cost
iMX
Exchangeable Head End Mills
