22
APX
30
0
60
APX
Holder
APX3000-050A07RA
Insert (Grade)
AOMT123620PEER-M (MP9130)
Work Material
Inconel® 718
Cutting Speed
vc30 m/min (n190 min-1)
Feed
fz0.03 mm/tooth (vf40 mm/min)
Depth of Cut
ap1 mm, ae40 mm
Coolant
Emulsion
Double-phased
helical rake
angles
Tough cutting edge
(Convex curve)
Key Point on Machining
Ni-based alloys that have low thermal conductivity and are prone to work hardening
require a superior coated grade combined with an optimum cutting edge to be machined
effectively. APX series provides extended tool life due to an optimized cutting edge
geometry and new insert grade.
Application Example
Achieved double tool life compared to conventional products.
High rigidity cutter bodies
Low cutting resistance insert
Face and Profile milling
ENGINE
Work Material [Ni-based Superalloy]
Conventional
Tool life (min)
