10
ae 20 mm
ap 25 mm
End mill
CSRARBD2500R300 (ø 25/R3)
Work Material
A7075
Cutting Speed
vc1178 m/min (n15000 min
-1
)
Feed
fz0.22 mm/tooth (vf10000 mm/min)
Depth of Cut
ap25 mm, ae20 mm
Coolant
Emulsion
Avoids poor wall surface finishes because the tool is designed to
interpolate corners of the pocket, thereby also preventing vibration.
15000min-1/75kW, BT50
Alimaster
Face Milling
Pocket Milling
Improved chip removal
Chip flow Chip flow
Unstable
chip flow.
Smooth chip
separation
AIR FRAME
Work Material [Aluminium Alloy]
Key Point on Machining
Milling of rib type components involves removing large volumes of stock material.
Therefore highly efficient machining at high speeds is required to reduce costs.
The ALIMASTER series achieves good chip removal and efficiency due to the unique cross-
sectional shape of the flute geometry.
Application Example
Chip removal of 5000cm
3
/min. is achieved when using a high power machine at high speeds.
<Machine specification>
Competitor
Alimaster
Point
